Trilliant® Cube LED Work Lights
Designed with a high lumen per watt rating, the Trilliant Cube provides high-quality light that fits where other lights just won’t work. Grote's sleek, rugged design with superior LED electronic circuitry outperforms lights twice its size and weight. Quality electronic components and advanced Grote circuit design provides electronically quiet operation, consistent light output, and protection from voltage spikes and electromagnetic interference. Premium LEDs produce white light that reduces eye fatigue and operator stress. Rugged design withstands heavy vibration, corrosion, moisture, and dust.
63W613000 Lumens, Close Range, Deutsch, 9-32V
63W613000 Lumens, Close Range, Deutsch, 9-32V
- Includes heat management and transient protection technology for enhanced LED life
- Premium level EMC requirements won't interfere with radio signals
- Highly efficient circuit board produces 68 lumens per watt across all voltages
- Pigtail not included
Technical specifications
- Material: Polycarbonate
- Color: White
- Lens Color: Clear
- Voltage: 9-32V
- Amperage: 2.6A, 1.3A
- Lumens: 3000
- Light Pattern: Close Range
- Color Temperature: 5700K
- Mounting Type: Pendant
- Connection Type: Deutsch
- Ingress Protection: IPX7, IP6K9K
- Height: 100 mm
- Length: 75 mm
- Regulations: ECE
- VMRS: 034-006-031
- Product Type: Work Light
- Product Line: Trilliant®
- Shape: Rectangular, Square
- Warranty: 3 Years
Compare
0 Product Added
Technical specifications
- Material: Polycarbonate
- Color: White
- Lens Color: Clear
- Voltage: 9-32V
- Amperage: 2.6A, 1.3A
- Lumens: 3000
- Light Pattern: Close Range
- Color Temperature: 5700K
- Mounting Type: Pendant
- Connection Type: Deutsch
- Ingress Protection: IPX7, IP6K9K
- Height: 100 mm
- Length: 75 mm
- Regulations: ECE
- VMRS: 034-006-031
- Product Type: Work Light
- Product Line: Trilliant®
- Shape: Rectangular, Square
- Warranty: 3 Years
Features & benefits
- Includes heat management and transient protection technology for enhanced LED life
- Premium level EMC requirements won't interfere with radio signals
- Highly efficient circuit board produces 68 lumens per watt across all voltages
- Pigtail not included
- All- weather design means consistent, reliable light for the task duration regardless of conditions
- Die-Cast aluminum housing and stainless steel mounting bracket for the toughest environmental conditions
- Highest quality electronic components and advanced Grote circuit design provides electronically quiet operation. This ensures long life, consistent light output, and protection from voltage spikes and electromagnetic interference
- Hardened lens to prevent scratches or fading from exposure to the sun
- Water-tight even when using high pressure cleaners
Viewing 0 / 20 products
Filter by
| Product # | Image | Voltage | Mounting Type | Connection Type | Light Pattern | Lumens |
|---|
Additional information
Grote Trilliant® Cubes are compact, bright, and fit where other lamps won’t. Designed with a high lumen per watt rating, the Cube provides high quality light that fits where other lamps just won’t work.
The Trilliant® Cube's sleek, rugged design with superior LED electronic circuitry outperforms lamps twice its size and weight. Quality electronic components and advanced Grote circuit design provides electronically quiet operation, consistent light output, and protection from voltage spikes and electromagnetic interference. Premium LEDs produce white light that reduces eye fatigue and operator stress. Rugged design withstands heavy vibration, corrosion, moisture, and dust.
Sophisticated reflector optics put more light on the task. Multiple connector options, DT-2 Pin and Amp SuperSeal, increase operational flexibility. Advanced circuit design and thermal management ensures consistent light output for the life of the lamp.
